Ashcroft(雅斯科) DG25 通用型数字压力表

Ashcroft(雅斯科) DG25 通用型数字压力表
Features

• Manufactured by Ashcroft

• 0.5% terminal point accuracy
• Five-digit LCD display with large .48" character size
• bar graph display (20 segment)
• Nine engineering units of measure
• Measuring gauge, vacuum and compound ranges from -14.7psi through 25,000 psi
• IP67 weatherproof enclosure
• Operating temp: -4 to 140°F (-20 to 60°C)

  Description:

  General Purpose Digital Pressure Gauge Model DG25



  Features:

  # 5 digit LCD display with 12 mm character size

  # New bar graph display (20 segment)

  # Nine engineering units of measure plus one user programmable unit

  # Capable of measuring gauge, vacuum and compound ranges from -1 bar

  through 1600 bar

  # IP67 weatherproof enclosure

  # CE compliant, RoHS compliant, UL and cUL 61010-1 (approval pending)



  # The versatile and economical choice for a wide variety of applications


  Applications:

  The Ashcroft® DG25 series offers 0.5% of span accuracy, while the laser welded stainless steel sensor and socket make this product suitable for use with a wide variety of pressure media in demanding industrial applications. This series is also available with enhanced accuracy of 0.25% of span making it suitable for many test and measurement uses. IP 67 ingress protection rating means the DG25 is suitable for

   demanding applications such as equipment wash down. Nine preprogrammed engineering units of measure to read pressure in units applicable to the process or familiar to the technician using the gauge.



  The DG25 comes standard with many features such as: tare, min and max memory, programmable custom engineering units, and pressure ranges from vacuum to 25,000 psi. The DG25 was designed with the OEM in mind and can easily be custom configured to meet unique requirements, add or delete features and be customized with private label keypad overlays. Contact Ashcroft or your authorized distributor to discuss your OEM requirements!
