FLOWLINE（氟莱）DL24超声波液位计

应用

通用超声波液位变送器提供连续物位测量可达980'（3米）与4-20 mA的输出信号，并通过我们免费的WebCal的软件配置。 液位传感器有4个具有可选择的滞后和故障安全逻辑，可编程的继电器。 嵌入式液位控制器可以通过更换外部控制硬件成本更低。 这种非接触式液位传感器非常适合腐蚀性，粘性或脏污的液体，并为天槽，防滑，IBC，水池和水箱的过程级应用广泛选择。



特征


产品规格

Features

• Manufactured by Flowline

• Level detection, switch and control functions up to 9.8’ (3m)
• Configuration is fast and easy via WebCal software and USB adapter
• Narrow 2” beam width and short 4” dead band optimized for small tanks
• Four programmable relays for switch, pump or valve control and fail-safety
• 1 pump or valve with 3 alarms
• 2 pumps (lead-lag) with 2 alarms
• 2 pumps (duplexing) with 2 alarms
• 4 independent switch point alarms
• PVDF transducer and 6P polycarbonate enclosure for corrosive liquids
• Automatic temperature compensation
• RoHS
• CE
• FM Approved

The DL24 general purpose ultrasonic level transmitter provides continuous level measurement up to 9.8' (3m) with a 4-20 mA signal output, and is configured via our free WebCal software. The level sensor has 4 programmable relays with selectable hysteresis and fail-safe logic. The embedded level controller can lower cost by replacing external control hardware. This non-contact liquid level sensor is ideally suited for corrosive, sticky or dirty liquids, and is widely selected for day tank, skid, IBC, sump and process tank level applications.

The DL24 is configured via our free WebCal PC software and Fob USB adapter. The sensors are offered with and without Fobs. Fobs are universal and can be used to configure any WebCal compatible product. Call Instrumart to request your free copy of WebCal.

• corrosive
• sticky or dirty liquids
