FLOWLINE（氟莱）DX10超声波液位计

FLOWLINE（氟莱）DX10超声波液位计应用

通用超声波液位变送器提供连续物位测量高达49.2“（1.25米）与可选择0-5 VDC，0-10 VDC或976-2000赫兹的频率信号输出，并通过我们免费的WebCal的软件配置。选择与模拟输入卡接口的电压输出。选择离散输入卡接口的输出频率。这种非接触式液位传感器非常适合腐蚀性，粘性或脏污的液体，并为小天槽，防滑，IBC广泛选择，油箱和油箱的过程级应用。



FLOWLINE（氟莱）DX10超声波液位计特征


Features

• Manufactured by Flowline

• Sensor provides 0-5 VDC, 0-10 VDC or 976-2000 Hz level measurement
• Compact sensor with 2” beam width and 2” dead band optimized for small tank applications
• Rugged PVDF transducer and polycarbonate enclosure rated 6P for corrosive media

The Flowline EchoPod DX10 ultrasonic sensor provides general purpose non-contact level measurement in small tanks. The DX10 includes an encapsulated, corrosion resistant, and submersible polycarbonate enclosure that is well suited for a wide range of corrosive, sticky or dirty type media. The DX10 is suitable for small atmospheric tank, IBC, drum, skid or process vessel and sump applications.

The Flowline EchoPod DX10 has a measuring range of up to 49.2" (1.25m) with an accuracy of 0.125" (3 mm). The sensor includes 0-5 VDC, 0-10 VDC or 976-2000Hz signal outputs. Users can select the voltage output to directly replace a contact measurement sensor connected to a PLC analog input. The frequency output can be selected to replace a contact measurement sensor or switch assembly, and eliminate the cost of an analog input card by connecting the DX10 to a PLC discrete input.

The Flowline EchoPod DX10 level sensor is configured using Flowline's WebCal software and Fob USB interface tool. A single configuration can be easily created, saved, duplicated, emailed or modified. Take control of your level process with WebCal's intuitive interface, pre-programmed menus, tank set point graphics and custom wiring diagrams for each of your configurations. It's level configuration made simple.
