ADI’s Dia-Vac® Pumps can pass your gas at the speed of need! Due to an increased interest in reducing the pressure, vacuum, and/or flow on the Dia-Vac® pumps, our engineers designed a modified eccentric design. This allows you to customize your Dia-Vac® pump to meet your application requirements while at the same time increasing the diaphragm and bearing life. The standard eccentric size is 0.160 on the B-Series Dia-Vac® Pump.
Please note that the chart below is not meant to be read as a combination of pressure and vacuum at the same time, only pressure or vacuum.
B系列DIA-VAC® 气体采样泵
|
B系列DIA-VAC® 气体采样泵 流量表
(Please click on individual Model # for actual performance curves)
|
||||||
|---|---|---|---|---|---|---|
| Model # |
PSIG (Max Pressure) |
Bar Gauge (Max Pressure) |
InHg Gauge (Ultimate Vacuum) |
Mbar Gauge (Ultimate Vacuum) |
SCFM (Max Flow) |
SLPM (Max Flow) |
|
B081
|
8.5
|
0.59
|
14.9
|
505
|
0.138
|
3.9
|
|
B101
|
12.9
|
0.89
|
17.4
|
589
|
0.155
|
4.4
|
|
B121
|
18.1
|
1.25
|
20.2
|
684
|
0.2
|
5.7
|
|
B141
|
23.4
|
1.61
|
21.4
|
725
|
0.24
|
6.8
|
|
B161
|
29.2
|
2.01
|
23.0
|
778
|
0.268
|
7.6
|
|
34.3 / NA
|
2.36 / NA
|
22.2 / 27.5
|
752 / 931
|
0.45 / 0.26
|
12.6 / 6.4
|
|
